I have created a modbus_tcp server demo program via sdyssockets.lib in codesys system. This server support 01，03，05，06，15，16 modbus function codes.

VAR_GLOBAL
VIRTUALPOS: LREAL;
TEST_T:INT;
input_byte:ARRAY[1..250] OF BYTE;
input_byte1:ARRAY[1..250] OF BYTE;
mw_area AT %MB1000:ARRAY[1..500] OF BYTE;
mx_area : ARRAY[1..512] OF BOOL;
output_byte: ARRAY[1..250]OF BYTE;
mw_temp AT%MW1000: ARRAY[1..500] OF INT;
write_len:INT;
send_do: BOOL;
mw_area_use AT %MW2000:ARRAY[1..500] OF INT;
ton2: TON;
test_trigger: BOOL;
t1: TON;
receive1_tmp:BYTE;
flag:BOOL;
addressPointer:POINTER TO SOCKADDRESS;
address:SOCKADDRESS;
ip:STRING:='192.168.39.100'; （PLC IP ADDRESS）
receive1:ARRAY[1..300] OF BYTE;
port: WORD:=502; （MODBUS——TCP port）
objectArray:ARRAY[0..6] OF REAL;
tcp_connect_state:BOOL;
tcp_connect_time1:TON;
tcp_connect_time2:TON;
get_last: BOOL;
protocol_id:INT;
device_id:INT;
send1:ARRAY[1..300] OF BYTE;
tttt AT %MD2000:ARRAY[1..100] OF DINT;
END_VAR

PROGRAM TCP_socket_test
VAR
result: BOOL;
socketId: DINT;
terminate: BOOL;
dwValue: DINT;

bResult: BOOL;
test_state: BOOL;
send: STRING;

error_now: BOOL;
time_trigger: BOOL;
SysSockGetLastError1:SysSockGetLastError;

MasterSocketList:SOCKET_FD_SET;
SlaveSocketList:SOCKET_FD_SET;
SelectTimeOut:SOCKET_TIMEVAL;
TCPindex: INT;
diSize: DINT;
TCPMax: DINT;

tcp_state: INT;
SocketHandle:DINT;
move_ref: INT;

END_VAR

PROGRAM ：TCP_socket_test
address.sin_addr:=SysSockInetAddr(ip);
address.sin_family:=SOCKET_AF_INET;
address.sin_port:=SysSockHtons(port);
addressPointer:=ADR(address);
IF terminate=FALSE THEN
CASE tcp_state OF
0:
socketId := SysSockCreate(SOCKET_AF_INET,SOCKET_STREAM,0);
IF socketId <> SOCKET_INVALID THEN
dwValue := 1;
(Set the option that we can reuse 'old' port addresses )
SysSockSetOption(socketId, SOCKET_SOL, SOCKET_SO_REUSEADDR, ADR(dwValue), SIZEOF (dwValue));
tcp_state := 10;
END_IF

10:bResult := SysSockBind(socketId, ADR(address), SIZEOF(address));
IF bResult THEN
tcp_state := 20;
END_IF

20:
bResult := SysSockListen(socketId, 255);
IF bResult THEN
MasterSocketList.fd_count := 1;
MasterSocketList.fd_array[0] := socketId;
tcp_state := 30;
END_IF

30:
SlaveSocketList:=MasterSocketList;

SelectTimeOut.tv_sec := 30;
SelectTimeOut.tv_usec := 0;
diSize := SysSockSelect(SOCKET_FD_SETSIZE, ADR(SlaveSocketList), 0, 0, ADR(SelectTimeOut));
IF diSize > 0 THEN
tcp_state := 50;
TCPindex := 0;
END_IF

50:
SocketHandle := SlaveSocketList.fd_array[TCPindex];
IF SocketHandle = socketId THEN
diSize := SIZEOF(Address);
SocketHandle:=SysSockAccept(socketId, ADR(Address), ADR(address));
IF SocketHandle <> SOCKET_INVALID THEN
TCPMax := SocketHandle;
MasterSocketList.fd_array[MasterSocketList.fd_count] := SocketHandle;
MasterSocketList.fd_count := MasterSocketList.fd_count + 1;
END_IF
tcp_state := 100;
END_IF

100:

( SysSockSend(socketId,ADR(send),SIZEOF(send),1);)
SysSockRecv(SocketHandle,ADR(receive1),SIZEOF(receive1),1);
FOR move_ref:=7 TO receive1[6]+7 DO
input_byte1[move_ref-6] :=receive1[move_ref];
END_FOR;
protocol_id:=BYTE_TO_INT(receive1[4]);
device_id:=BYTE_TO_INT(receive1[7]);
IF protocol_id=0 AND device_id>=0 AND receive1[1]<>0 THEN (modbus_tcp,protocol_id=0)
frame_process();
tcp_state := 120;
END_IF;

120:
IF send_do THEN
send1[1]:=receive1[1];send1[2]:=receive1[2];
send1[3]:=0;send1[4]:=0;
send1[5]:=0;send1[6]:=INT_TO_BYTE(write_len-2);
FOR move_ref:=7 TO 7+(write_len-2) DO
send1[move_ref]:=output_byte[move_ref-6];
END_FOR;

SysSockSend(SocketHandle,ADR(send1),(write_len-1+6),1);
receive1[1]:=0;
send_do:=FALSE;
END_IF;
tcp_state := 100;

END_CASE;
END_IF;

IF terminate = TRUE THEN ( close socket )
SysSockClose(socketId);
socketId := 0;
tcp_state:=0;
result := FALSE;

END_IF

PROGRAM frame_process
VAR

length_check:INT;
   crc_out:WORD;
    crc_temp:WORD;
    address_temp:INT;
    move_to_send:INT;
   byte_len:INT;
  mod_state:INT;
length_temp: INT;
length_check1: INT;
crc_out1: WORD;
  write_area:ARRAY[1..250] OF BYTE;
    x:INT;
    control_temp: WORD;
          offset_temp:INT;

END_VAR
Frame_process
IF (( input_byte1[1]<16#FF) AND( input_byte1[1]>=0)) AND( (input_byte1[2]=01) OR (input_byte1[2]=05) OR( input_byte1[2]=03 ) OR( input_byte1[2]=6 )OR(input_byte1[2]=16)OR(input_byte1[2]=15)) THEN
(CRC16 check action )
IF input_byte1[2]=03 OR input_byte1[2]=06 OR input_byte1[2]=01 OR input_byte1[2]=05 THEN
length_check:=6;
END_IF;

 IF input_byte1[2]=16  OR  input_byte1[2]=15 THEN
length_check:=7+input_byte1[7];
END_IF;

( crc_check( lengthcrc:= length_check,
inbyte:=input_byte1,
CRC16CVT=>crc_out );
crc_temp:=SHL(BYTE_TO_WORD(input_byte1[length_check+1] ),8) OR BYTE_TO_WORD(input_byte1[length_check+2] );)

( CRC16 check OK then the process is going on ,judge the function code to response )
IF ( ( crc_out = crc_temp<>0) AND) (send_do =FALSE )THEN
CASE input_byte1[2] OF
01:(read the coils)
output_byte[1]:=17; output_byte[2]:=01;
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8) + ( BYTE_TO_INT(input_byte1[4]));
length_temp:=SHL(BYTE_TO_INT(input_byte1[5]),8) +(BYTE_TO_INT(input_byte1[6]));
mod_state:=length_temp MOD 8;
IF mod_state<>0 THEN
byte_len:=1+length_temp/8;
ELSE
byte_len:=length_temp/8;
END_IF;
output_byte[3]:=INT_TO_BYTE(byte_len);
FOR move_to_send:=4 TO byte_len+3 DO
IF mod_state=0 THEN
output_byte[move_to_send].0:=mx_area[address_temp+1+(move_to_send-4)*8]; output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
output_byte[move_to_send].4:=mx_area[address_temp+(move_to_send-4)*8+5]; output_byte[move_to_send].5:=mx_area[address_temp+(move_to_send-4)*8+6];
output_byte[move_to_send].6:=mx_area[address_temp+(move_to_send-4)*8+7]; output_byte[move_to_send].7:=mx_area[address_temp+(move_to_send-4)*8+8];
ELSE
IF move_to_send=byte_len+3 THEN
CASE mod_state OF
1: output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send]:=output_byte[move_to_send] AND 16#0001;
2: output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
output_byte[move_to_send]:=output_byte[move_to_send] AND 16#0003;

             3:   output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
                   output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send]:=output_byte[move_to_send] AND 16#0007;

             4:   output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
                   output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
                    output_byte[move_to_send]:=output_byte[move_to_send] AND 16#000F;

              5: output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
                   output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
                   output_byte[move_to_send].4:=mx_area[address_temp+(move_to_send-4)*8+5];    output_byte[move_to_send]:=output_byte[move_to_send] AND 16#001F;

               6:output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
                   output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
                   output_byte[move_to_send].4:=mx_area[address_temp+(move_to_send-4)*8+5];    output_byte[move_to_send].5:=mx_area[address_temp+(move_to_send-4)*8+6];
                   output_byte[move_to_send]:=output_byte[move_to_send] AND 16#003F;

                7:output_byte[move_to_send].0:=mx_area[address_temp+(move_to_send-4)*8+1];output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
                   output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
                   output_byte[move_to_send].4:=mx_area[address_temp+(move_to_send-4)*8+5];    output_byte[move_to_send].5:=mx_area[address_temp+(move_to_send-4)*8+6];
                     output_byte[move_to_send].6:=mx_area[address_temp+(move_to_send-4)*8+7];     output_byte[move_to_send]:=output_byte[move_to_send] AND 16#007F;

            END_CASE;
             ELSE
          output_byte[move_to_send].0:=mx_area[address_temp+1+(move_to_send-4)*8]; output_byte[move_to_send].1:=mx_area[address_temp+(move_to_send-4)*8+2];
         output_byte[move_to_send].2:=mx_area[address_temp+(move_to_send-4)*8+3]; output_byte[move_to_send].3:=mx_area[address_temp+(move_to_send-4)*8+4];
         output_byte[move_to_send].4:=mx_area[address_temp+(move_to_send-4)*8+5]; output_byte[move_to_send].5:=mx_area[address_temp+(move_to_send-4)*8+6];
         output_byte[move_to_send].6:=mx_area[address_temp+(move_to_send-4)*8+7]; output_byte[move_to_send].7:=mx_area[address_temp+(move_to_send-4)*8+8];
           END_IF;
         END_IF;
          END_FOR;
      length_check1:=3+byte_len;
    (*  crc_check( lengthcrc:= length_check1,
                      inbyte:=output_byte,
                      CRC16CVT=>crc_out1 );
      output_byte[4+byte_len]:= WORD_TO_BYTE(SHR((crc_out1 AND 16#FF00 ),8));
      output_byte[5+byte_len]:= WORD_TO_BYTE(crc_out1 AND 16#FF );*)
       write_len:= 5+byte_len;send_do:=TRUE;

15:(force multi coils)
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8) + ( BYTE_TO_INT(input_byte1[4]));
length_temp:=SHL(BYTE_TO_INT(input_byte1[5]),8) +(BYTE_TO_INT(input_byte1[6]));

         mod_state:=length_temp MOD 8;

        FOR move_to_send:=address_temp TO address_temp+length_temp-1  BY 8 DO
             offset_temp:=move_to_send-address_temp;
             IF mod_state=0 THEN
            mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;
            mx_area[move_to_send+5]:=input_byte[offset_temp/8+8].4;mx_area[move_to_send+6]:=input_byte[offset_temp/8+8].5;
            mx_area[move_to_send+7]:=input_byte[offset_temp/8+8].6;mx_area[move_to_send+8]:=input_byte[offset_temp/8+8].7;
            ELSE
              IF move_to_send-address_temp-length_temp+1<=8 THEN
               CASE mod_state OF
              1:  mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;
              2:  mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
              3:  mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;

              4: mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;

              5:  mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;
            mx_area[move_to_send+5]:=input_byte[offset_temp/8+8].4;

              6:mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;
            mx_area[move_to_send+5]:=input_byte[offset_temp/8+8].4;mx_area[move_to_send+6]:=input_byte[offset_temp/8+8].5;

             7:  mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;
            mx_area[move_to_send+5]:=input_byte[offset_temp/8+8].4;mx_area[move_to_send+6]:=input_byte[offset_temp/8+8].5;
            mx_area[move_to_send+7]:=input_byte[offset_temp/8+8].6;
                END_CASE;
               ELSE
            mx_area[move_to_send+1]:=input_byte[offset_temp/8+8].0;mx_area[move_to_send+2]:=input_byte[offset_temp/8+8].1;
            mx_area[move_to_send+3]:=input_byte[offset_temp/8+8].2;mx_area[move_to_send+4]:=input_byte[offset_temp/8+8].3;
            mx_area[move_to_send+5]:=input_byte[offset_temp/8+8].4;mx_area[move_to_send+6]:=input_byte[offset_temp/8+8].5;
            mx_area[move_to_send+7]:=input_byte[offset_temp/8+8].6;mx_area[move_to_send+8]:=input_byte[offset_temp/8+8].7;

               END_IF;

           END_IF;
         END_FOR;

      FOR move_to_send:=2 TO 6 DO
      output_byte[move_to_send]:=input_byte1[move_to_send];
      END_FOR;

output_byte[1]:=17;
length_check1:=6;
( crc_check( lengthcrc:= length_check1,
inbyte:=output_byte,
CRC16CVT=>crc_out1 );
output_byte[7]:= WORD_TO_BYTE(SHR((crc_out1 AND 16#FF00 ),8));
output_byte[8]:= WORD_TO_BYTE(crc_out1 AND 16#FF );)
write_len:= 8;send_do:=TRUE;

05: (force the coil)
FOR move_to_send:=2 TO 8 DO
output_byte[move_to_send]:=input_byte1[move_to_send];
END_FOR;
output_byte[1]:=17;
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8)+ BYTE_TO_INT(input_byte1[4]);
control_temp:=INT_TO_WORD(SHL(BYTE_TO_INT(input_byte1[5]),8) +(BYTE_TO_INT(input_byte1[6])));
IF control_temp=16#FF00 THEN
mx_area[address_temp+1]:=TRUE;
END_IF;
IF control_temp=16#0000 THEN
mx_area[address_temp+1]:=FALSE;
END_IF;
write_len:= 8;send_do:=TRUE;

03:(read the registers)
output_byte[1]:= 17; output_byte[2]:=03;
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8) + ( BYTE_TO_INT(input_byte1[4]));
length_temp:=SHL(BYTE_TO_INT(input_byte1[5]),8) +(BYTE_TO_INT(input_byte1[6]));
output_byte[3]:=INT_TO_BYTE((length_temp)2);
FOR move_to_send:=address_temp TO address_temp+(length_temp)2 DO
output_byte[4+move_to_send-address_temp]:=mw_area[move_to_send+address_temp+1];
END_FOR;
length_check1:=3+(length_temp)2;
( crc_check( lengthcrc:= length_check1,
inbyte:=output_byte,
CRC16CVT=>crc_out1 );
output_byte[4+(length_temp)*2]:= WORD_TO_BYTE(SHR((crc_out1 AND 16#FF00 ),8));
output_byte[5+(length_temp)*2]:= WORD_TO_BYTE(crc_out1 AND 16#FF );)
write_len:= 5+(length_temp)2;send_do:=TRUE;

16:( write the registers)
FOR move_to_send:=2 TO 6 DO
output_byte[move_to_send]:=input_byte1[move_to_send];
END_FOR;
output_byte[1]:=17;
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8)+ BYTE_TO_INT(input_byte1[4]);
length_temp:=SHL(BYTE_TO_INT(input_byte1[5]),8)+ BYTE_TO_INT(input_byte1[6]);
FOR move_to_send:=address_temp TO address_temp+(length_temp)2-1 DO
mw_area[move_to_send+address_temp+1]:=input_byte1[8+move_to_send-address_temp];
END_FOR;
length_check1:=6;
( crc_check( lengthcrc:= length_check1,
inbyte:=output_byte,
CRC16CVT=>crc_out1 );
output_byte[7]:= WORD_TO_BYTE(SHR((crc_out1 AND 16#FF00 ),8));
output_byte[8]:= WORD_TO_BYTE(crc_out1 AND 16#FF );*)
write_len:= 8;send_do:=TRUE;

06:(force the single register)
FOR move_to_send:=2 TO 8 DO
output_byte[move_to_send]:=input_byte1[move_to_send];
END_FOR;
output_byte[1]:=17;
address_temp:=SHL(BYTE_TO_INT(input_byte1[3]),8)+ BYTE_TO_INT(input_byte1[4]);
mw_area[address_temp*2+1]:=input_byte1[5];mw_area[address_temp*2+2]:=input_byte1[6];
write_len:= 8;send_do:=TRUE;

END_CASE;

END_IF;

Talk.ru: 1
Talk.ru: 2
Talk.ru: 3
Talk.ru: 5
Talk.ru: 7
Talk.ru: 8

Forums

Help

modbus_tcp_server in codesys via syssockets.lib

Related

Forums

Help

modbus_tcp_server in codesys via syssockets.lib document.SUBSCRIPTION_OPTIONS = { "thing": "topic", "subscribed": false, "url": "subscribe", "icon": { "css": "fa fa-envelope-o" } };

Related

modbus_tcp_server in codesys via syssockets.lib
