I use Codesys Control Win MC 3.5 SP16 and I created in my existing application two new arrays of [600,3000,650] OF BOOL. When I try to download the application, it shows up an error message "Out of global data memory. I tried clean all and retried the download with no sucess and I deleted persistent varibales too. Is there a way to increase the memory? My PC has 16Gb of memory and it has memory available. Where I can access the configuration to chance this? Thanks!
Last edit: leandroct 2022-03-25
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
That is a pretty big array. It has 1170000000 entries. If you use a 32-bit runtime, I assume each BOOL eats up a whole 4-byte word, so this works out to more than 4Gb of memory, which would typically be the limit a 32-bit process can address under the best circumstances.
If you are using a 64-bit runtime, this doubles the memory used because memory is addressed in 8-byte words. I am not sure a 9GB+ contiguous array should be expected to fit in a machine with 16GB of memory, but if it does there sure is little room to grow.
Maybe you should pack your BOOL values as single bits, which will obviously require a bit of fun with bitwise operators and translating "bit addresses" to byte+bit parts. You would increase your density by a factor of 32 or 64, which should easily fit in your available memory
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
A BOOL is stored as 1 byte, 8 BOOLs are stored in 1 64-bit word or 2 32-bit word.
But even if you pack 8 BOOLs/byte you have 1,4 GB of data for each array. And this is a giant code smell for PLC code. That's why the default size is 4 kB (almost always you need less than 1 kB), not including visualization which gets a separate area.
If I guessed correctly your target application, at least 99.99% of these BOOLs will always be FALSE. Perhaps you should look into sparse matrices representation?
Anyway, this post is a clear example of the XY Problem: https://xyproblem.info/ so please detail what is the original problem you are trying to solve.
For reference:
You can override runtime memory size by right clicking on Application -> Properties -> Target memory settings -> Override memory settings, but the max you can go is 2 GB (you'd need at least 3 GB with those arrays).
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
A BOOL is a 1-byte value, but the CPU reads and writes memory as 4-byte values (32-bit) or 8-byte values (64-bit). The actual space occupied by a BOOL in a structure will depend on the packing mode. If BOOL arrays use single byte alignment, this means CODESYS performs byte-manipulation under the hood, which is certainly possible. I would like to know if this is documented somewhere, and a reliable behavior irrespective of platform.
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
1-byte variables are always packed at byte addresses irrespective of the pack mode.
You can verify experimentally for yourself (I did it on x86, x86_64, ARM Cortex-A and PowerPC e200z7).
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
Thanks to all by the answers.
- I use 64 bits Codesys.
- I saw the Target memory settings that you said, sgronchi. Thanks! But really it canβt reach my needed memory even if I increase my PC memory, if I understood.
- To explain about why I want this big array, my application does a 3D reading of an area with size x(600cm), y(3000cm) and z(650cm). To create a logic that navigate in the space to analyze the objects and surfaces is very hard to me unless I could put the read points in a 3D array. In this case, each BOOL representing 1 square cm is enough for me. The BOOL array TRUE values would vary, but I think 5 to 10% is a default we can imagine.
- Interesting the Sparce Matrix idea. I can think about it.
If I have no solution by this way, then I will need to think in a new way. But my main question here was answered by sgronchi. Thanks to all!
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
So I guessed correctly that you were trying to build a point cloud (and that's where the "at least 99.99% will always be FALSE" came from ;-) ) and that's exactly the reason why they're always stored in a sparse matrix (that could range from a simple linear array storing coordinates to more complex data structures).
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
I couldn't imagine a logic that would analyze the readings next to the current point, in all 3D directions, without having to convert the sparse matrix into a 3D matrix before processing (only in the region analyzed at the moment). That would solve it, but I'm guessing I'll have processing speed issues. But I will analyze. Thank you again.
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
If you are only doing a touch-probe scan, you could get away with a linear array or even with a "last point", i.e. 6 coordinates, and move by delta (maybe checking that you did not touch that point before).
If you would like to refer to this comment somewhere else in this project, copy and paste the following link:
